Number 6 marks the part’s position in the exploded view.
Product overview
Genuine OEM Volkswagen Pinion Shaft, part number 02J409177D. This shaft transmits rotational force from the driveshaft to the differential gears. It is a key component within the transmission assembly, indicated by diagram position 6. This part weighs 0.213 kg. Genuine OEM pinion shafts are precisely machined to ensure proper meshing with other gears and to withstand the torque loads of the drivetrain.
Technical details
- Category
- Transmission & Drivetrain
- Country of origin
- Germany
- Customs (HS) code
- 73182900
- Manufacturer
- Volkswagen
- Product Type
- Genuine new auto parts
- Shipping size (L × W × H)
- 10.9 × 1.8 × 1.8 cm
- Shipping weight
- 0.21 kg
Parts diagram & fitment
22 vehiclesShaft - Differential Pinion — locate 02J409177D Volkswagen Pinion Shaft | Transmission Component in the official exploded view and explore the surrounding assembly.
Parts in this assembly(31)
- 1Housing 02A409121D
- 2Gear Set 02A409143S
- 3Fixing Set 02A498088A
- 4Thr Washer 01M409170
- 5Diff Pinio 02S498081B
- 7Sleeve N90538701
- 9Mounting 113517185B
- 10Washer 02A409210A
- 10Washer 02A409210B
- 10Washer 02A409210C
- 10Washer 02A409210D
- 10Washer 02A409210E
- 10Washer 02A409210F
- 10Washer 02A409210G
- 10Washer 02A409210H
- 10Washer 02A409210J
- 10Washer 02A409210K
- 10Washer 02A409210L
- 10Washer 02A409210M
- 10Washer 02A409210
- 11Seal 084409189B
- 12Flanshaft 02A409355D
- 13Drivewheel 02A409187B
- 14Pinion 02A409197
- 15Guide 02A409193
- 20Seal 02J409528A
- 21Press Spring 084409379
- 22Washer 02J409378
- 23Ring 020409374
- 24Circlip N90564501
- 25Screw 02J409359
Diagrams & fitment data powered by oemdiagrams.com
02J409177D Volkswagen Pinion Shaft | Transmission Component is fitted on: POLO CLASSIC/VARIANT 1999-2001; BORA (FAW) 2001-2006; Jetta USA 2001-2005; New Beetle 2001-2005; New Beetle Cabrio. 2003-2005; Jetta/Wagon 2002-2006; Golf 'R32' n. "USA" 2004-2004; Jetta City "MEX"05>07 2006-2007; New Beetle 06> 2005-; New Beetle Cabrio. 06> 2005-; POLO CLASSIC "ZA"05> 2005-; CADDY-KOMBI/KASTENW. 06> 2005-; POLO CLASSIC 06> 2005-; Jetta City "Mex"08> 2007-; FABIA/COMBI 1999-2004; OCTAVIA/COMBI/4X4 01> 2000-; FABIA/COMBI 05> 2004-; ROOMSTER 06> 2006-; FABIA/COMBI NF 07> 2006-; AUDI A2 2000-2005; Audi TT Coupe/Roadster 2002-2006; CORDOBA/VARIO 1999-2002.
