Radiator exploded parts diagram — Passat saloon · 2014-2024, position 1
Exploded view
Passat saloon · 2014-2024 · position 1Full diagram ↓
04L131512E

04L131512E Radiator

€478.18
incl. 21% VAT

€395.19 excl. VAT

Supersession roadforks into 2
  1. 04L131512EThis pageNot stocked
    Dec 2016
  2. 04L131512BMNot stocked
    Feb 2019
  1. 04L131512CCCurrent number
  2. 03N145735MCurrent number
Availability: No longer supplied under this number

Special order item. Delivery time may vary.

About This Part

Superseded part number

This part number has been replaced. Order the current replacement shown above — the old number can no longer be supplied.

Order Processing & Delivery

This part is not stocked in our warehouse and will be ordered directly from the manufacturer upon purchase. Handling time for VOLKSWAGEN is typically 3–8 business days before dispatch.

Handling time for VAG (VW / Audi / Seat / Cupra): 3–8 business days from order confirmation to dispatch (Monday–Friday). Shipping transit for your country is added on top — see handling times by brand and shipping options.

* Delivery times are estimates and may vary based on manufacturer availability and your location.

Verify Vehicle Fitment

To ensure this part is compatible with your vehicle, please contact us with your VIN (Vehicle Identification Number). Our technical team can verify the exact fitment before you place your order.

Contact us with your VIN
Genuine OEM Parts
Direct from manufacturer
Secure Ordering
Safe and protected checkout

Parts diagram & fitment

1 vehicle

Radiator — locate Radiator in the official exploded view and explore the surrounding assembly.

Parts in this assembly37
Vehicle fitment table1

Europe (1)

VehicleYearsPos.Qty
Passat saloon2014-202411

Diagrams & fitment data powered by oemdiagrams.com

Radiator is fitted on: Passat saloon 2014-2024.
