Number 23 marks the part’s position in the exploded view.
Product overview
Genuine OEM Audi Engine Thermostat, part number 059115201H. This essential component regulates the engine coolant temperature, ensuring the engine operates within its optimal thermal range for efficiency and longevity. It is typically located within the oil filter/cooler assembly. This cylindrical thermostat weighs 0.063 kg. Opting for a genuine OEM thermostat guarantees accurate temperature calibration and reliable operation, which is crucial for preventing engine overheating or undercooling, both of which can lead to reduced performance and increased wear.
Technical details
- Category
- Engine Cooling
- Customs (HS) code
- 90321080
- Manufacturer
- Audi
- Product Type
- Genuine new auto parts
- Shipping size (L × W × H)
- 17.7 × 2.8 × 2.8 cm
- Shipping weight
- 0.06 kg
Parts diagram & fitment
15 vehiclesThermostat — locate 059115201H Audi Engine Thermostat | Regulates Temperature in the official exploded view and explore the surrounding assembly.
Superseded by N91087401 — the later replacement part.
Parts in this assembly(48)
- 1Screw N10170302
- 2Cover 059115423E
- 3Seal Ring N91087401
- 5Screw N10554005
- 6Screw N10405702
- 7Pressure 05E906060A
- 7Sensor 06E906054J
- 8Filterelem 059198405D
- 9Cover 059115311D
- 9Cover 059115311F
- 11Oil Filter 059115389AL
- 11Oil Filter 059115389AP
- 12Seal 059115446E
- 13Bolt N10405604
- 14Sensor 079919523H
- 15Seal Ring WHT002287B
- 16Oil Cooler 059117015K
- 17Seal 059117070J
- 17Gasket 059117070K
- 18Bolt N10124309
- 19Bungs 04E115418B
- 19Stud 059115418A
- 20Seal Ring WHT004757
- 21Screw N10473402
- 22Bracket 059131694CN
- 23Tube 059115630CA
- 23Tube 059115630CG
- 24Bolt N91126601
- 25Seal Ring 034115427B
- 26Screw WHT004874
- 27Screw N91196501
- 28Seal Ring N0138326
- 29Seal D176501A1
- 30Seal 059103610J
- 31Part 055105277
- 32Oil Sump 059103603FE
- 33Screw WHT004873
- 34Seal Ring 06M115475
- 35Valve 06M115393D
- 35Valve 06M115393F
- 35Valve 06M115393G
- 36Bolt N10196103
- 37Insert 059103138BM
- 38Bolt N10745101
- 39Oil Pump 059115103CD
- 39Oil Pump 059115103CP
- 40Bolt N10745301
- 41Chn Sprckt 059109570F
Compatible / alternative parts(4)
- Part 059115423E
- Part 059115446E
- Part 034115427B
- Part N0111513
Diagrams & fitment data powered by oemdiagrams.com
059115201H Audi Engine Thermostat | Regulates Temperature is fitted on: Audi Q8 Quattro 3,0 2018-; audi a6 2.0 2018-; Audi A7 Sportback 2018-; Audi A6 Av. qu. 3.0 2012-2018; Audi A7 Sportback 2014-2018; audi a6 qu. 3.0 tdi 2014-2018; Audi A8L 2017-2022; Audi A5 Cabrio 2.0 2016-2018; audi a4 2.0 2015-2019; Audi Q7 qu. 3.0 TDI 2015-2019; Audi Q5 2016-2020; Audi A5 Sportback 2016-2020; Amarok twin cab 2022-; touareg 2017-2023; Amarok twin cab 2016-2022.
