Target · Diagram
Find this reference above
Number 8 marks the part’s position in the exploded view.
Product overview
Genuine OEM Audi Intake Manifold, part number 1K0129565AE. This critical component is responsible for distributing air evenly from the throttle body to each of the engine's cylinders, ensuring balanced combustion. It is mounted directly to the engine's cylinder head. Weighing 0.2254 kg and measuring 0.32 m in length, this manifold is engineered to precise specifications, guaranteeing proper airflow dynamics and sealing, which is essential for engine performance and fuel efficiency.
Technical details
- Category
- Intake & Turbo
- Country of origin
- Austria
- Customs (HS) code
- 84099100
- Manufacturer
- Audi
- Product Type
- Genuine new auto parts
- Shipping size (L × W × H)
- 32 × 15 × 8.5 cm
- Shipping weight
- 0.23 kg
Parts diagram & fitment
5 vehiclesIntake Manifold — locate 1K0129565AE Audi Intake Manifold | Air Distribution in the official exploded view and explore the surrounding assembly.
Parts in this assembly(28)
- 1Air Filter 3C0129607BE
- 1Air Filter 3C0129607BD
- 2Air Filter 1K0129620E
- 2Air Filter 1K0129620G
- 2Air Filter 1K0129620D
- 3Seal Ring 028129646
- 4Bolt 1K0129381
- 5Insert 3C0129668A
- 5Insert 3C0129668
- 6Air Meter 03L906461
- 7Bolt N91179601
- 8Part 1K0129565AC
- 9Part 3C0145830
- 10Grommet 867129669
- 12Hose 3C0129654AG
- 12Hose 3C0129654M
- 13Pipe 5N0906391
- 14Clamp N90656101
- 15Adapter 3C0129635
- 16Seal Ring 3C0129646
- 17Clamp N10296001
- 18Hose 1K0129637D
- 19Air Guide 1K0129618BQ
- 21Connection 03L129711AL
- 22Seal 03L129717J
- 22Seal 03L129717H
- 23Screw N91117502
- 24Rectifier 3C0129363
Diagrams & fitment data powered by oemdiagrams.com
1K0129565AE Audi Intake Manifold | Air Distribution is fitted on: new beetle 2011-2016; new beetle cabriolet 2011-2016; jetta 2014-2017; caddy kombi 2015-2020; Yeti 2013-2017.
