Number 30 marks the part’s position in the exploded view.
Product overview
Genuine OEM Volkswagen Lock Carrier, part number 2H0805563F. This is the main structural component at the front of the vehicle that houses and supports the radiator, intercooler, and other front-end modules. It is located at the very front of the vehicle's chassis. Genuine OEM lock carriers are critical for maintaining the precise alignment of cooling systems and impact absorption structures, ensuring proper function and safety.
Technical details
- Category
- Body Exterior
- Customs (HS) code
- 87082990
- Manufacturer
- Volkswagen
- Product Type
- Genuine new auto parts
- Shipping size (L × W × H)
- 103.5 × 22 × 11.3 cm
- Shipping weight
- 2.26 kg
Parts diagram & fitment
1 vehicleLock Carrier — locate 2H0805563F Volkswagen Lock Carrier | Genuine OEM in the official exploded view and explore the surrounding assembly.
Superseded by 2H0807094 — the later replacement part.
Parts in this assembly(22)
- 1Side Member 2H0805102
- 1Side Member 2H0805133A
- 5Wheel HousingRight2H0805116A
- 5Wheel HousingLeft2H0805115
- 10Pillar ARight2H0805192
- 10Pillar ALeft2H0805191
- 15Cross PanRight2H2805431
- 15Cross PanRight2H2805431A
- 15Cross PanLeft2H1805431
- 15Cross PanLeft2H1805431A
- 17Valve 2H0819419
- 20SupportRight2H0805472A
- 20SupportLeft2H0805471A
- 25Cross Member 2H0805541
- 25Cross Member 2H6805541
- 30Carrier 2H0805563E
- 35Retaining 2H2805603
- 40Clos ElementRight2H0809882
- 40Clos ElementLeft2H0809881
- 100Pop Rivet N90812302
- 105Bolt N10653201
- 105Bolt N10668401
Compatible / alternative parts(11)
Diagrams & fitment data powered by oemdiagrams.com
2H0805563F Volkswagen Lock Carrier | Genuine OEM is fitted on: Amarok twin cab 2012-2016.
