Number 2 marks the part’s position in the exploded view.
Product overview
Genuine OEM Volkswagen Oval Hexagon Socket Head Bolt, part number 3Q0804841E. This specialized bolt is used for securing components, particularly within the high-voltage battery system. It is located at position 2 in the diagram. Genuine OEM bolts are manufactured to precise tolerances for strength and reliability, ensuring the secure fastening of critical components in demanding applications like battery systems.
Technical details
- Category
- Battery & Charging
- Country of origin
- Spain
- Customs (HS) code
- 87082990
- Manufacturer
- Volkswagen
- Product Type
- Genuine new auto parts
- Shipping size (L × W × H)
- 93 × 61.5 × 11.8 cm
- Shipping weight
- 3.15 kg
Parts diagram & fitment
5 vehiclesBattery Case Upper Section — locate 3Q0804841E Volkswagen Bolt | Genuine OEM in the official exploded view and explore the surrounding assembly.
Superseded by 3Q0804841F — the later replacement part.
This part is marked discontinued by the manufacturer; contact us to check current availability.
Parts in this assembly(24)
- 2Housing 3Q0804841F
- 3Valve 3Q0915754A
- 4Housing 3Q0804842K
- 5Control Un 5WA915250C
- 5Control Un 5WA915250D
- 6Dampingmat 3Q0907352G
- 7Bolt N91055301
- 8Guide 3Q0911457A
- 9Guide 3Q0911457B
- 10Dampingmat 3Q0907352
- 11Support 3Q0972901D
- 12Support 3Q0972901C
- 13Adapter 3Q0915155
- 14Sleeve 7T0915820
- 15Screw N91233701
- 16Bolt N10676801
- 17Sign 12E010006S
- 18Sign 12E010001B
- 20Warning Sign 1EA010505
- 21Heat Sh 7T0825755A
- 22Adhesive D469101A3
- 23Cleaner D00940104
- 24Sleeve 7T0915820A
- 26Insulation 3Q0915474
Diagrams & fitment data powered by oemdiagrams.com
3Q0804841E Volkswagen Bolt | Genuine OEM is fitted on: Multivan 2021-; Passat saloon 2014-2024; Tiguan 2.0 4Motion 2016-2024; Audi Q3 quattro 2018-2019; Tarraco FR 2018-2024.
