Number 7 marks the part’s position in the exploded view.
Product overview
Genuine OEM Volkswagen Heat Protection Sleeve, part number 4M1723523E. This sleeve is designed to protect nearby components from excessive heat generated by the engine or exhaust system, contributing to the longevity of those parts. It is located in the pedal assembly area. Genuine OEM heat protection sleeves are made from materials that withstand high temperatures and maintain their protective properties.
Technical details
- Category
- Engine
- Customs (HS) code
- 87089997
- Manufacturer
- Volkswagen
- Product Type
- Genuine new auto parts
- Shipping size (L × W × H)
- 33 × 16.5 × 8 cm
- Shipping weight
- 2.02 kg
Parts diagram & fitment
6 vehiclesAccelerator Pedal With Electronic Module — locate 4M1723523E Volkswagen Heat Protection Sleeve | Genuine OEM in the official exploded view and explore the surrounding assembly.
LThis part is the Left side
Superseded by 4M1723523F — the later replacement part.
This part is marked discontinued by the manufacturer; contact us to check current availability.
Parts in this assembly(32)
- 1Bracket 4M1723117D
- 1Bracket 4M1723117F
- 1Accel PedLeft4M1723523F
- 1Bracket 4M1723117E
- 2Part 8D1723309A
- 3Bolt N10714801
- 4Ret Washer N90070306
- 5Pedal 4M1723140
- 6Ap Cap For Foot Brake Pedal Cap For Foot Brake 8W1723173A
- 6Ap Cap For Foot Brake Pedal Cap For Foot Brake 8W1723173
- 7Accel PedLeft4M1723523D
- 7Accel PedLeft4M1723523G
- 7Accel PedLeft4N1723523
- 7Accel PedLeft4N1723523A
- 7Accel PedLeft8W1723523
- 7Accel PedLeft8W1723523A
- 8Screw N10734001
- 11Collar Nut N90456002
- 12Ap Cap For Accelerator Pedal Cap For 8W0721173
- 13Bracket 4M2723117D
- 13Bracket 4M2723117E
- 13Bracket 4M2723117B
- 14Part 8K2721329
- 16Ret Washer N91148401
- 17Pedal 4M2723140
- 18Ap Cap For Foot Brake Pedal Cap For Foot Brake 4M2723173
- 18Ap Cap For Foot Brake Pedal Cap For Foot Brake 8W2723173
- 19Accel PedRight4M2723523B
- 19Accel PedRight4M2723523C
- 19Accel PedRight4M2723523D
- 19Accel PedRight4M2723523E
- 21Bolt N10805001
Diagrams & fitment data powered by oemdiagrams.com
4M1723523E Volkswagen Heat Protection Sleeve | Genuine OEM is fitted on: Audi Q8 Quattro 3,0 2018-; audi a6 2.0 2018-; Audi A7 Sportback 2018-; Audi A8L 2017-2022; Audi Q7 qu. 3.0 TDI 2015-2019; touareg 2017-2023.
