Number 8 marks the part’s position in the exploded view.
Product overview
Genuine OEM Volkswagen Fresh Air Flap, part number 5NB863935B. This flap regulates the flow of fresh air into the vehicle's cabin. It is located at position 8 in the diagram. Genuine OEM flaps ensure precise air intake control and proper sealing for efficient HVAC system operation.
Technical details
- Category
- Heating & A/C
- Customs (HS) code
- 87082990
- Manufacturer
- Volkswagen
- Product Type
- Genuine new auto parts
- Shipping size (L × W × H)
- 150 × 93 × 26 cm
- Shipping weight
- 6.89 kg
Parts diagram & fitment
3 vehiclesDamping For Cowl — locate 5NB863935B Volkswagen Fresh Air Flap | Genuine OEM in the official exploded view and explore the surrounding assembly.
Superseded by 5NB863935C — the later replacement part.
This part is marked discontinued by the manufacturer; contact us to check current availability.
Parts in this assembly(31)
- 1Sound Abs 5NA863831
- 1Sound Abs 5NG863831A
- 2Clip 1T0863727
- 4Damping 5QB863353B
- 4Damping 5QB863353E
- 4Damping 5QB863353F
- 4Damping 5QB863353G
- 5Washer N90335004
- 6Sound Abs 5NA863993
- 6Sound Abs 5NA863993B
- 6Sound Abs 5NA863993C
- 7Damping 5TA864453A
- 7Insulation 5TA864453
- 8Damping 5NB863934B
- 8Damping 5NB863934C
- 8Damping 5NB863934E
- 8Damping 5NB863935A
- 9Press Stud N90871301
- 10InsulationLeft5NA864235C
- 10InsulationRight5NA864236E
- 12Insulation 5NA864237B
- 13Sound Abs 5NA864760A
- 13Sound Abs 5NA864759A
- 14Insulation 571864725A
- 14Insulation 5NA864725
- 20Insulation 5NA863919A
- 20Insulation 5NR863919
- 25Part 000863890
- 25Part 000864663
- 262 Pk Foam D506KD1A3
- 26Butyl Strp AKL45000505
Compatible / alternative parts(3)
- Part 5NL863919
- Part 5NN863919B
- Part 5NN863367B
Diagrams & fitment data powered by oemdiagrams.com
5NB863935B Volkswagen Fresh Air Flap | Genuine OEM is fitted on: Tiguan 2.0 4Motion 2016-2022; Tiguan 2.0 4Motion 2017-2024; Tiguan 2.0 4Motion 2016-2024.
