Number 4 marks the part’s position in the exploded view.
Product overview
Genuine OEM Volkswagen Ashtray Assembly, part number 5Q0711049AN. This assembly combines an ashtray, cigarette lighter, and a drink holder for convenience. It is located at position 4 in the diagram. Genuine OEM parts ensure exact fit and function, maintaining the original quality and design of your vehicle's interior.
Technical details
- Category
- Body Interior
- Country of origin
- Slovakia
- Customs (HS) code
- 87089997
- Manufacturer
- Volkswagen
- Product Type
- Genuine new auto parts
- Shipping size (L × W × H)
- 147 × 14.5 × 33.5 cm
- Shipping weight
- 2.44 kg
Parts diagram & fitment
12 vehiclesSelector Mechanism — locate 5Q0711049AN Volkswagen Ashtray Assembly | Genuine OEM in the official exploded view and explore the surrounding assembly.
Superseded by 5Q0711049AP — the later replacement part.
This part is marked discontinued by the manufacturer; contact us to check current availability.
Parts in this assembly(48)
- 1GearstickLeft5G1711113A
- 1KnobLeft5G1711113B
- 1KnobLeft5G1711113C
- 1KnobLeft5G1711113D
- 1GearstickRight5G2711113
- 1GearstickRight5G2711113A
- 1KnobRight5G2711113B
- 1KnobRight5G2711113C
- 1KnobRight5G2711113D
- 1GearstickLeft5G1711113
- 2Badge 5K0711144C
- 2Badge 5K0711144B
- 3Clip N10255501
- 10Seal 1K0711267B
- 11Insulation 1K0711047
- 14Press Spring 5Q0711145A
- 17Lever 5Q0711112E
- 17Lever 5Q0711112F
- 18Seal 5Q0711267E
- 21Part N90714303
- 24Cable 5Q0711266
- 25Cable 5Q0711265N
- 26Cable Tie 3W0971838
- 27Clip 1K0711637
- 28Bolt N10106905
- 29Abutment 1K0711789G
- 29Abutment 5Q0711789
- 29Abutment 5Q0711789A
- 30Grommet 357711798
- 31Spacer 1J0711795D
- 32Collar Nut N90761103
- 33Ret Washer 1J0711280C
- 35Catch 5N0711761
- 36Piece 6Q0711550
- 37Lever 5Q0711202A
- 37Lever 5Q0711202B
- 37Lever 5Q0711202
- 38Clip 1K0711522
- 40Catch 1K0711761B
- 41Lever 5Q0711046J
- 41Lever 5Q0711046K
- 41Lever 5Q0711046H
- 42Ret Washer N90815903
- 51Mechanism 5Q0711049AJ
- 51Mechanism 5Q0711049AM
- 51Mechanism 5Q0711049AP
- 51Mechanism 5Q0711049AQ
- 51Mechanism 5Q0711049AR
Compatible / alternative parts(1)
Diagrams & fitment data powered by oemdiagrams.com
5Q0711049AN Volkswagen Ashtray Assembly | Genuine OEM is fitted on: Golf 1.4 BlueMotion 2012-2017; Golf Estate 2013-2017; golf 2.0 2016-2020; golf 1.6 2015-2019; Audi A3 Sportback 2012-2016; Audi A3 Cab. 1.4 2013-2016; Audi A3 Sportback 2016-2020; Audi A3 Cabrio 2016-2020; Leon ST Stylance 2012-2016; Leon ST Stylance 2016-2020; Octavia 2012-2017; Octavia 2017-2020.
