Number 1 marks the part’s position in the exploded view.
Product overview
Genuine OEM Volkswagen Constant Velocity Joint Assembly, part number 5QF201060BE. Transmits power from the transmission to the wheels while allowing for suspension movement. Located in the drivetrain assembly. Manufactured to exact specifications for smooth power transfer and durability under load.
Technical details
- Category
- Transmission & Drivetrain
- Customs (HS) code
- 87089997
- Manufacturer
- Volkswagen
- Product Type
- Genuine new auto parts
- Shipping size (L × W × H)
- 130 × 104 × 80 cm
- Shipping weight
- 7.94 kg
Parts diagram & fitment
2 vehiclesFuel Tank — locate 5QF201060BE Volkswagen CV Joint Assembly | Genuine OEM in the official exploded view and explore the surrounding assembly.
Superseded by 5QF201060BF — the later replacement part.
This part is marked discontinued by the manufacturer; contact us to check current availability.
Parts in this assembly(27)
- 1Container 5QF201060CB
- 1Container 5QF201060CG
- 1Container 5QF201060P
- 2Fuel Line 5Q0201294E
- 2Fuel Line 5QF201294B
- 3Fuel Line 5QF201293E
- 3Fuel Line 5QF201293H
- 3Fuel Line 5QF201293D
- 4Part 5QF201607
- 8Heat Sh 5Q0201307F
- 8Heat Sh 5QF201307B
- 9Part N91068501
- 10Strap 5QF201656D
- 10Strap 5QF201656C
- 12Bolt N91229601
- 13Repair Kit 3Q0298112A
- 14End Piece 895201890
- 15Bolt N10699801
- 16Line 5QA201142
- 16Line 5WA201142G
- 17Bush 5QA201048
- 18Bush 5Q0201693
- 19Rubber Bush 5Q0201840
- 20Insulation 8K0201274B
- 21Part 1K0201375
- 28Clamp N10203501
- 29Clamp N10056801
Compatible / alternative parts(12)
Diagrams & fitment data powered by oemdiagrams.com
5QF201060BE Volkswagen CV Joint Assembly | Genuine OEM is fitted on: Tiguan 2.0 4Motion 2016-2024; Kodiaq 2016-2024.
