Number 1 marks the part’s position in the exploded view.
Product overview
5QF201060L Volkswagen Oval Hexagon Socket Head Bolt
A specialized bolt used for securing various engine and fuel system components.
- Genuine OEM
- Condition: New
- Part number: 5QF201060L
- Part type: Oval Hexagon Socket Head Bolt
- Position on diagram: 1
Verify fitment by VIN or matching the part number before ordering.
Technical details
- Category
- Engine
- Country of origin
- Germany
- Customs (HS) code
- 87089997
- Manufacturer
- Volkswagen
- Product Type
- Genuine new auto parts
- Shipping size (L × W × H)
- 145 × 120 × 78 cm
- Shipping weight
- 7.94 kg
Parts diagram & fitment
7 vehiclesFuel Tank — locate 5QF201060L VW Tiguan Bolt Genuine OEM in the official exploded view and explore the surrounding assembly.
Superseded by 5QF201060P — the later replacement part.
This part is marked discontinued by the manufacturer; contact us to check current availability.
Parts in this assembly(18)
- 3Fuel Line 5Q0201293H
- 5Part 5QD201550B
- 6Seal Ring 1K0201557A
- 7Clip 1J0201250
- 8Heat Sh 5Q0201307F
- 9Part N91068501
- 10Strap 5QF201656C
- 12Bolt N91229601
- 13Container 5QG201801
- 14Bolt N10240003
- 15Clip 1H0201449C
- 16Bolt N10699801
- 17Line 5QA201142
- 18Bush 5QA201048
- 19Bush 5Q0201693
- 20Rubber Bush 5Q0201840
- 21Insulation 8K0201274B
- 22Part 1K0201375
Compatible / alternative parts(12)
Diagrams & fitment data powered by oemdiagrams.com
5QF201060L VW Tiguan Bolt Genuine OEM is fitted on: Tiguan 2016-2023; Tiguan 2.0 4Motion 2016-2022; Tiguan 2.0 4Motion 2017-2024; Tiguan 2.0 4Motion 2016-2024; Kodiaq 2018-2022; Kodiaq 2017-2022; Kodiaq 2016-2024.
