Number 16 marks the part’s position in the exploded view.
Product overview
Genuine OEM Volkswagen Wheel Bearing Cover, part number 5QM505436. This cover is designed to protect the wheel bearing from contaminants and debris. It is a crucial component for maintaining the integrity of the wheel hub assembly. The part is located on the wheel hub assembly. Genuine OEM parts are manufactured to exact specifications for optimal performance and protection.
Technical details
- Category
- Body Exterior
- Customs (HS) code
- 87085099
- Manufacturer
- Volkswagen
- Product Type
- Genuine new auto parts
- Shipping size (L × W × H)
- 31 × 27.5 × 11 cm
- Shipping weight
- 4.4 kg
Parts diagram & fitment
5 vehiclesWheel Bearing Housing — locate 5QM505436 Volkswagen Wheel Bearing Cover | Genuine OEM in the official exploded view and explore the surrounding assembly.
RThis part is the Right side
Parts in this assembly(28)
- 1Bracket 1K0505130L
- 1Bracket 1K0505129L
- 1AAp Cover Cap For Bearing Support Cover Cap ForRight1K0501476
- 1AAp Cover Cap For Bearing Support Cover Cap ForLeft1K0501475
- 2Axle GuideRight5QM505224
- 2Axle GuideLeft5QM505223
- 3Rubber Bush 5Q0505541A
- 4Bolt N90648402
- 5Bolt N10769501
- 6BoltRightWHT005748
- 6ScrewLeftWHT005747
- 7Wishbone 5QM505311
- 9Washer WHT000232
- 10Bolt WHT000227
- 11Bolt WHT000228
- 12Collar Nut N10106402
- 13Wishbone 5Q0505323C
- 16HousingLeft5QM505435
- 17Rubber Bush 1K0505553A
- 18Bolt N91197801
- 19Washer 1K0505193
- 20Collar Nut N10401801
- 21Bolt N10640501
- 23Bolt WHT007150
- 24Part 1J0501249C
- 25Part N10597701
- 26Bracket 1K0614167C
- 28Wheel Hub 5QM501611
Compatible / alternative parts(12)
Diagrams & fitment data powered by oemdiagrams.com
5QM505436 Volkswagen Wheel Bearing Cover | Genuine OEM is fitted on: POLO HATCH "ZA"06> 2005-; Golf 1.4 BlueMotion 2014-2017; Golf Estate 1.4 2014-2017; golf 1.6 2015-2019; Audi A3 Limousine 2.0 2015-2016.
