Number 1 marks the part’s position in the exploded view.
Product overview
Genuine OEM Volkswagen Seat Frame Bolt, part number 5Z4881046E. This bolt is used to secure components within the seat assembly. It is a threaded fastener designed for tool engagement. Genuine OEM seat frame bolts ensure precise fitment and material integrity for long-lasting structural support within the seat.
Technical details
- Category
- Seats
- Customs (HS) code
- 94019080
- Manufacturer
- Volkswagen
- Product Type
- Genuine new auto parts
- Shipping size (L × W × H)
- 71 × 54 × 16.5 cm
- Shipping weight
- 4.3 kg
Why buy from WW Spares?
- ✓ Genuine OEM inventory sourced directly from factory networks
- ✓ Fitment support from workshop-seasoned parts specialists
- ✓ Global logistics with customs-ready documentation
Need help confirming compatibility? Talk to a specialist
Parts diagram & fitment
8 vehiclesBackrest Frame — locate 5Z4881046E Volkswagen Seat Frame Bolt | Genuine OEM in the official exploded view and explore the surrounding assembly.
RThis part is the Right side
This part is marked discontinued by the manufacturer (since 2023-05-01); contact us to check current availability.
Parts in this assembly48
- 1Frame-back 2H0881045
- 1Frame-backLeft6Q4881045AL
- 1Frame-back 6R3881045AD
- 2Guide 6Q0881595A
- 2Cable 5Z0881595
- 3Spring 1J3881619
- 4PanelLeft5Z0881607
- 5Clip 6H0881635
- 6HandleLeft1J3881633B
- 7Ring 1J0881493
- 7Knob 5Z0881671
- 7Knob 1J0881671F
- 7Knob 6R0881671D
- 8Trim 5Z0881480
- 8Trim 6Q3881477C
- 8Trim 6Q4881477B
- 9Trim 2H0881478
- 9Trim 2K0881480A
- 9Trim 2K0881480
- 10Screw 373881353
- 10Bolt 377881261A
- 10Bolt 5Z0881261
- 10Bolt N90895901
- 10Bolt N90699002
- 11Rollers 377881295A
- 11Rollers 5Z0881295
- 11Ring 1J3881493
- 12Spring 1J0881497
- 13Ring 5Z0881476
- 15Ret Washer N90052702
- 16Sleeve 5X3881197
- 17Wire 1J0881483E
- 17Wire 6Q0881883
- 19Clip N90902001
- 24Guide 1T0883920E
- 25Guide 1T0883920C
- 30Headrest 2H0881901AB
- 30Headrest 2H0881901AD
- 30Headrest 2H0881901AJ
- 30Headrest 2H0881901AK
- 30Headrest 2H0881901AL
- 30Headrest 2H0881901AM
- 30Headrest 2H0881901L
- 30Headrest 2H0881901M
- 40Padding 2H0881775
- 40Padding 2H0881775B
- 40Padding 2H0881775C
- 40Padding 5Z0881775
Vehicle fitment table8
Europe (3)
| Vehicle | Years | Pos. | Qty | Remark | PR |
|---|---|---|---|---|---|
| Amarok twin cab | 2012-2016 | 1 | |||
| Amarok twin cab | 2009-2012 | 1 | 1 | PR:K4E+3TB | K4E |
| FOX 04> | 2003- | 1 | 1 | 3H0 |
Other markets (5)
| Vehicle | Years | Pos. | Qty | Remark | PR |
|---|---|---|---|---|---|
| Crossfox | 2014-2021 | 1 | 1 | 1U8 | |
| Spacefox | 2014-2019 | 1 | 1 | PR:1U8+3H0 | 1U8 |
| Spacefox | 2010-2014 | 1 | 1 | PR:1U8+3H0 | 1U8 |
| Crossfox | 2009-2014 | 1 | 1 | PR:1U8+3H0 | 1U8 |
| SURAN (FOX MPV) "RA."06> | 2006- | 1 | 1 | 3H0 |
Diagrams & fitment data powered by oemdiagrams.com
5Z4881046E Volkswagen Seat Frame Bolt | Genuine OEM is fitted on: Amarok twin cab 2012-2016; Amarok twin cab 2009-2012; FOX 04> 2003-; Crossfox 2014-2021; Spacefox 2014-2019; Spacefox 2010-2014; Crossfox 2009-2014; SURAN (FOX MPV) "RA."06> 2006-.
