Number 23 marks the part’s position in the exploded view.
Product overview
Genuine OEM Volkswagen Body Cover, part number 7H0815713. This cover protects and conceals components of the vehicle's body. It is located at position 23 in the diagram. The cover is made of durable material to withstand environmental factors. Genuine OEM body covers ensure precise fitment and factory-quality protection.
Technical details
- Category
- Heating & A/C
- Customs (HS) code
- 87082990
- Manufacturer
- Volkswagen
- Product Type
- Genuine new auto parts
- Shipping size (L × W × H)
- 10 × 8.5 × 5.5 cm
- Shipping weight
- 0.1 kg
Parts diagram & fitment
26 vehiclesCover — locate 7H0815713 Volkswagen Body Cover | Genuine OEM in the official exploded view and explore the surrounding assembly.
Parts in this assembly(48)
- 1Housing 7L0819087K
- 3Temperature Sensor 1K0907543A
- 4Bracket 7L0819147
- 5Sealg Cord 7H0819211
- 6Part 7L0819351F
- 6Part 7L0819351G
- 6Part 7L0819351H
- 6Part 7L0819351J
- 6Part 7L0819351K
- 6Part 7L0819351L
- 7Seal 7H0819064B
- 7APart 7L5819410
- 8Temperature Sensor 4B0820539
- 9Bracket 7L0819259
- 11Part 7L0819352B
- 11Part 7L0819352
- 14Air Guide 7H0898409
- 15Seal 7L0820513E
- 15Seal 7L0820513D
- 16Bracket 7H0820660
- 17Seal Ring 8E0260749
- 18Seal Ring 7H0820749
- 19Screw N0199091
- 20Od Filter 7E0819631
- 20Dust Filt 7H0819631A
- 20Part JZW819653E
- 21Heat Exch 7L0819031A
- 21Heat Exch 7L0819031
- 22Seal Ring N90973201
- 23Clamp Spring 7H0819139
- 24Part 7L0820536
- 26Cover 7L0815159A
- 26Cover 7L0815159
- 28Cover 7H1819422A
- 29Drain Tube 7L0820119B
- 30Seal 7L0819143B
- 30Seal 7L0819143C
- 31Part 7L0815153A
- 31Part 7L0815153B
- 31Part 7L0815153C
- 31Housing 7L0815153
- 32Part 7L0907521B
- 32Part 7E0959263
- 34Blower 7L0820021Q
- 34Blower 7L0820021R
- 34Blower 7L0820021S
- 34Blower 7L0820021T
- 36Clip 7H0819059
Diagrams & fitment data powered by oemdiagrams.com
7H0815713 Volkswagen Body Cover | Genuine OEM is fitted on: Touareg 2003-2005; 7L6 platform; TRANSPORTER 2003-2005; CAMPMOBILE(T5) 2004-2006; Touareg 2005-2006; TRANSPORTER/4MOTION 06 2005-2006; TRANSPORTER 06 2005-2006; TRANSPORTER/4MOTION 07 2006-2007; TRANSPORTER OFFEN (7J) 07 2006-2007; CAMPMOBIL (T5) 07 2006-2007; Touareg 08> 2007-; TRANSPORTER GESCHL. 08 2007-; TRANSPORTER OFFEN 08 2007-; CAMPMOBIL-T5 08 2007-; transp. caravelle 2008-2009; transp. dropside 2008-2009; California Camper 2008-2009; transp. caravelle 2009-2011; transp. dropside 2009-2011; California Camper 2009-2011; transp. caravelle 2011-2015; transp. dropside 2011-2015; California Camper 2011-2015; Audi Q7 07> 2006-; Audi Q7 qu. 3.0 TDI 2009-2015.
