Number 16 marks the part’s position in the exploded view.
Product overview
Genuine OEM Volkswagen Main Fuse Socket, part number 7H0823509A. This socket provides a secure housing for main fuses, protecting critical electrical circuits. It is located within the vehicle's electrical system. Genuine OEM parts ensure correct electrical conductivity and reliable protection.
Technical details
- Category
- Electrical & Wiring
- Customs (HS) code
- 83023000
- Manufacturer
- Volkswagen
- Product Type
- Genuine new auto parts
- Shipping size (L × W × H)
- 86 × 13.5 × 3 cm
- Shipping weight
- 0.45 kg
Parts diagram & fitment
14 vehiclesLid Lock With Microswitch — locate 7H0823509A Volkswagen Main Fuse Socket | Electrical in the official exploded view and explore the surrounding assembly.
This part is marked discontinued by the manufacturer; contact us to check current availability.
Parts in this assembly(35)
- 1Bonnet 7H0823033D
- 2HingeRight7H0823302D
- 2HingeLeft7H0823301D
- 3Stop 1H5827681B
- 4Bolt N10155906
- 5G Fill Str 7H0823359C
- 6Clip 443823397
- 7Support 7H0823361C
- 8Rubber Bush 171823395
- 9Clip 357823397
- 10Stud 701827439B
- 11Buffer 7H0823434
- 11Buffer 7H0823429A
- 12Catch Hook 7H0823480C
- 13Bolt N90440702
- 15Buffer 357827500
- 17Switch 7H0953236
- 18Bolt N10553801
- 19Lid CableRight7H2823530A
- 19Lid CableLeft7H1823530A
- 20Bracket N10331401
- 21Cable Tie 3D0971838N
- 22Bracket N10484401
- 22Bracket 7D0955747A
- 23Bellows 3B0837861A
- 24HandleRight1J2823533C
- 24HandleLeft1J1823533C
- 25Bracket 7H0823573A
- 26Pop Rivet N90273201
- 27BracketRight7H2823633B
- 27BracketLeft7H1823633B
- 28Part 811807577C
- 29Bolt N90905902
- 33Gasket 7H0823737D
- 34Buffer N90003301
Compatible / alternative parts(5)
Diagrams & fitment data powered by oemdiagrams.com
7H0823509A Volkswagen Main Fuse Socket | Electrical is fitted on: TRANSPORTER 2003-2005; CAMPMOBILE(T5) 2004-2006; TRANSPORTER/4MOTION 06 2005-2006; TRANSPORTER 06 2005-2006; TRANSPORTER/4MOTION 07 2006-2007; TRANSPORTER OFFEN (7J) 07 2006-2007; CAMPMOBIL (T5) 07 2006-2007; TRANSPORTER GESCHL. 08 2007-; TRANSPORTER OFFEN 08 2007-; CAMPMOBIL-T5 08 2007-; transp. caravelle 2008-2009; transp. dropside 2008-2009; California Camper 2008-2009.
