9J1816198E Refrigerant Line
€267.90 excl. VAT
- 9J1816198EThis pageNot stocked
Nov 2022 - 9J1816198GCurrent number
Special order item. Delivery time may vary.
About This Part
Superseded part number
This part number has been replaced. Order the current replacement shown above — the old number can no longer be supplied.
Order Processing & Delivery
This part is not stocked in our warehouse and will be ordered directly from the manufacturer upon purchase. Handling time for VAG is typically 3–8 business days before dispatch.
Handling time for VAG (VW / Audi / Seat / Cupra): 3–8 business days from order confirmation to dispatch (Monday–Friday). Shipping transit for your country is added on top — see handling times by brand and shipping options.
* Delivery times are estimates and may vary based on manufacturer availability and your location.
Verify Vehicle Fitment
To ensure this part is compatible with your vehicle, please contact us with your VIN (Vehicle Identification Number). Our technical team can verify the exact fitment before you place your order.
Contact us with your VINParts diagram & fitment
2 vehiclesRefrigerant Line — locate Refrigerant Line in the official exploded view and explore the surrounding assembly.
Parts in this assembly36
- 1Line 9J1820033A
- 2Bolt N10700201
- 4Valve 8E0820855
- 5Seal Ring 4E0260749A
- 6Drier 992820077A
- 7Clamp N0245226
- 10Capacitor 9J1816412
- 12Bolt N91096801
- 13Bracket 9J1816594B
- 14Grommet 046131887
- 15Spacer 052129734
- 16Bolt N10632102
- 20Line 9J1820741B
- 21Seal Ring 4E0260749B
- 22Seal Ring 4D0260749B
- 24Valve 4M0816805B
- 26Line 9J1820729A
- 30Line 9J1820730A
- 33Screw N10470703
- 35Line 9J1820739B
- 38Bracket 9J1820137
- 42Part 9J1820249K
- 42Part 9J1820249L
- 44Part 4M0959603E
- 46Screw N10720901
- 50Part 9J1816198G
- 52Seal Ring 4E0260749C
- 53Seal Ring 8E0260749C
- 55Screw N10738801
- 60Line 9J1820742
- 65Valve 4M0816702A
- 70Line 9J1820743
- 78Bracket 9J1816575A
- 79Bolt N90737107
- 82Screw N91188301
- 83Thread Pin N10730601
Vehicle fitment table2
Europe (2)
| Vehicle | Years | Pos. | Remark |
|---|---|---|---|
| Audi RS e-tron GT | 2020-2020 | 50 | |
| Taycan Sport Turismo | 2019-2024 | 10 | 1 |
Diagrams & fitment data powered by oemdiagrams.com
Refrigerant Line is fitted on: Audi RS e-tron GT 2020-2020; Taycan Sport Turismo 2019-2024.
