Number 33 marks the part’s position in the exploded view.
Product overview
Genuine OEM Volkswagen Fuel Rail, part number JNV130125D. This fuel rail distributes pressurized fuel from the fuel pump to the engine's fuel injectors. It is located as part 33 in the diagram. The fuel rail has dimensions of 0.195m x 0.095m x 0.07m and weighs 0.86 kg. Genuine OEM fuel rails are critical for maintaining consistent fuel pressure and ensuring optimal engine combustion.
Technical details
- Category
- Fuel System
- Country of origin
- Italy
- Customs (HS) code
- 87089997
- Manufacturer
- Volkswagen
- Product Type
- Genuine new auto parts
- Shipping size (L × W × H)
- 19.5 × 9.5 × 7 cm
- Shipping weight
- 0.86 kg
Parts diagram & fitment
6 vehiclesFuel Rail — locate JNV130125D Volkswagen Fuel Rail | Genuine OEM in the official exploded view and explore the surrounding assembly.
Parts in this assembly(48)
- 1Rail 06A133317AS
- 2Valve 06A906031BT
- 3Seal Ring 035906149A
- 4Clip 037133047
- 5Valve 022133434
- 6Part 036133335
- 7Bolt WHT001926
- 8Fuel Line 1K0133986AJ
- 9Clamp N90686701
- 13Bolt N01021020
- 15Valve JNV906031A
- 18Part JNV906527
- 19Bolt N01028716
- 22Hose 5K0133321D
- 22Hose 5K0133321E
- 22Hose 5K0133321F
- 22Hose 5K0133321C
- 23Clamp 3C0131483
- 25Part JNV201393A
- 26Screw N10721401
- 27Bolt N10670301
- 28Bolt N10675602
- 29Collar Nut N90761102
- 30Part 6R0907642
- 32Evaporator 6R0133669A
- 33Insert 6R0201287
- 34Seal Ring 6R0201174
- 36Seal Ring 6R0133696
- 37Filterelem 6R0133843
- 38Ring N0122871
- 39Bracket JNV133095A
- 40Bolt N91011301
- 41Bolt N90999503
- 42Collar Nut N10205802
- 45Clamp N10201901
- 46Hose 5K0133321G
- 50Filter 6R0133511C
- 52Seal Ring 6R0127113C
- 52Seal Ring 6R0127113A
- 53Filterelem 6R0127177A
- 53Filterelem 6R0127177B
- 54Seal Ring 6R0127113
- 54Seal Ring 6R0127113B
- 56Bracket 5K0133095
- 57Bolt N90737105
- 61Fuel Line 5K0133291F
- 62Bracket 037133687BA
- 63Bracket 5K0133095A
Compatible / alternative parts(3)
Diagrams & fitment data powered by oemdiagrams.com
JNV130125D Volkswagen Fuel Rail | Genuine OEM is fitted on: golf 2.0 2008-2011; Golf Plus 1.6 2009-2011; Caddy Maxi Kombi 2010-2015; Golf 2011-2013; Golf Plus 2011-2014; Altea XL Reference 2013-2013.
