Number 2 marks the part’s position in the exploded view.
Product overview
Genuine OEM Volkswagen Heat Protection Sleeve, part number JZW253609G. This sleeve shields nearby components from the high temperatures generated by the exhaust system. It is located in the exhaust assembly. Made by Volkswagen.
Technical details
- Category
- Exhaust
- Country of origin
- Spain
- Customs (HS) code
- 87089235
- Manufacturer
- Volkswagen
- Product Type
- Genuine new auto parts
- Shipping size (L × W × H)
- 113.5 × 21.5 × 13 cm
- Shipping weight
- 6.18 kg
Parts diagram & fitment
10 vehiclesRear Silencer 'eco' — locate JZW253609G Volkswagen Heat Protection Sleeve | Exhaust System in the official exploded view and explore the surrounding assembly.
Superseded by JZW253609S — the later replacement part.
This part is marked discontinued by the manufacturer; contact us to check current availability.
Parts in this assembly(30)
- 1Exhaust Si 1J0253209N
- 1Exhaust Si 1J0253209P
- 1Exhaust Si 1J0253209Q
- 1Exhaust Si JZW253209
- 1Exhaust Si JZW253209A
- 1Exhaust Si JZW253209D
- 1Exhaust Si 1J0253209M
- 2Exhaust Si JZW253609S
- 3Exhaust Si JZW253609AA
- 3Exhaust Si JZW253609E
- 4Exhaust Si 1J6253609AE
- 4Exhaust Si 1J6253609CC
- 4Exhaust Si JZW253609AB
- 4Exhaust Si 1J6253609AR
- 5Exhaust Si 1J5253609AG
- 5Exhaust Si 1J5253609J
- 5Exhaust Si JZW253609AQ
- 5Exhaust Si JZW253609R
- 5Exhaust Si 1J5253609AF
- 6Bracket 1J0253144
- 7Clip 893253139A
- 7Clip 191253141F
- 7Clip 1H0253141B
- 8Bolt 111821145
- 9Part 1J0253144G
- 10Clip 357253141A
- 11Ut Hexagon Nut Self-locking Hexagon Nut N90074401
- 11Ut Hexagon Nut Self-locking Hexagon Nut N90074404
- 12Tunnel 1J0802117B
- 13Bracket 1J0253144J
Compatible / alternative parts(12)
Diagrams & fitment data powered by oemdiagrams.com
JZW253609G Volkswagen Heat Protection Sleeve | Exhaust System is fitted on: Golf 1998-2000; New Beetle 1998-2001; GOLF/VAR./4MOT. A4 02 2001-2002; New Beetle 2001-2005; New Beetle Cabrio. 2003-2005; Golf 'R32' n. "USA" 2004-2004; New Beetle 06> 2005-; New Beetle Cabrio. 06> 2005-; TOLEDO/LEON/LEON-4 1998-2001; TOLEDO/LEON/LEON-4 2001-2006.
