Number 13 marks the part’s position in the exploded view.
Product overview
JZW698520B Volkswagen Cv Joint Assembly
This assembly transmits power from the transmission to the wheels while allowing for suspension movement and steering angles.
- Genuine OEM
- Condition: New
- Part number: JZW698520B
- Part type: Cv Joint Assembly
- Position on diagram: 13
Verify fitment by VIN or matching the part number before ordering.
Technical details
- Category
- Transmission & Drivetrain
- Country of origin
- Germany
- Customs (HS) code
- 87083091
- Manufacturer
- Volkswagen
- Product Type
- Genuine new auto parts
- Shipping size (L × W × H)
- 18 × 15 × 5 cm
- Shipping weight
- 1.87 kg
Why buy from WW Spares?
- ✓ Genuine OEM inventory sourced directly from factory networks
- ✓ Fitment support from workshop-seasoned parts specialists
- ✓ Global logistics with customs-ready documentation
Need help confirming compatibility? Talk to a specialist
Parts diagram & fitment
35 vehicles1 Set: Brake Shoes With Linings — locate JZW698520B VW CV Joint Assembly Genuine OEM in the official exploded view and explore the surrounding assembly.
This part is marked discontinued by the manufacturer (since 2024-05-01); contact us to check current availability.
Parts in this assembly19
- 1Brake Drum 6Q0609617
- 2Bolt N10648301
- 3Back PlateRight6Q0609426
- 3Back PlateLeft6Q0609425
- 4Brake Cyli 6Q0611053C
- 5ScrewRightN90818302
- 6Valve 3A0611475
- 7Part 211611483
- 8Glidepiece 6N0609589
- 9Bungs 171609163
- 10Bolt N91006202
- 11Brake Shoe 6R0698525A
- 12Push Bar 6Q0609820B
- 12Push Bar 6Q0609819B
- 13Part JZW698511B
- 13Brake Shoe 6R0698520X
- 14Fixing Set 6R0698545A
- 15Fixing Set 6R0698545B
- 20Paste G000650
Vehicle fitment table35
Europe (35)
| Vehicle | Years | Pos. |
|---|---|---|
| Mii electric | 2020-2021 | 13 |
| Citigo | 2019-2021 | 13 |
| up! 1.0 BlueMotion | 2016-2023 | 13 |
| e-up! | 2016-2023 | 13 |
| Ibiza Stylance | 2015- | 13 |
| Polo 1.4 BlueMotion | 2014-2017 | 13 |
| e-up! | 2013-2016 | 13 |
| Polo | 2012-2014 | 13 |
| Ibiza Reference | 2012-2012 | 13 |
| Mii reference | 2011-2019 | 13 |
| Citigo | 2011-2019 | 11 |
| up! BlueMotion | 2011-2016 | 13 |
| Ibiza Reference | 2011-2012 | 13 |
| Polo | 2009-2014 | 13 |
| Polo | 2009-2012 | 13 |
| Ibiza Reference | 2008-2011 | 13 |
| Polo | 2008-2009 | 13 |
| FABIA/COMBI NF 07> | 2006- | 13 |
| FOX M.05> | 2005- | 11 |
| POLO | 2005- | 11 |
| CORDOBA 06> | 2005- | 13 |
| FABIA/COMBI 05> | 2004- | 13 |
| LUPO/3L TDI | 2003-2005 | 14 |
| POLO | 2001-2005 | 13 |
| FABIA/COMBI | 1999-2004 | 31 |
| POLO CLASSIC/VARIANT | 1999-2001 | 14 |
| POLO | 1999-2001 | 14 |
| LUPO/3L TDI | 1998-2003 | 14 |
| GOLF VAR./VENTO | 1996-1999 | 33 |
| POLO CLASSIC/VARIANT | 1996-1999 | 33, 14 |
| Golf | 1996-1997 | 33 |
| POLO | 1994-1999 | 14 |
| Golf Cabrio | 1994-1996 | 33 |
| Golf/Ecomatic 95 | 1994-1995 | 33 |
| Passat | 1989-1991 | 32 |
