Hex Collared Bolt exploded parts diagram — New Beetle 06> · 2005-, position 6 — New Beetle 06> · 2005- · position 6Full diagram ↓

N10257501

N10257501 Hex Collared Bolt

Name: N10257501 Hex Collared Bolt
Brand: Škoda
SKU: N10257501
Price: 5.03 EUR
Availability: InStock

€5.03

incl. 21% VAT

€4.16 excl. VAT

This is a catalog item (special order). Delivery time may vary.

Availability: Available to order

Quantity:

Special order item. Delivery time may vary.

About This Part

Available for Purchase

This part is available to order directly from the manufacturer. While it's not currently in our warehouse, we can source it for you and have it shipped to your location.

Order Processing & Delivery

This part is not stocked in our warehouse and will be ordered directly from the manufacturer upon purchase. Handling time for SKODA is typically 1–6 business days before dispatch.

Handling time for Skoda: 1–6 business days from order confirmation to dispatch (Monday–Friday). Shipping transit for your country is added on top — see handling times by brand and shipping options.

* Delivery times are estimates and may vary based on manufacturer availability and your location.

Verify Vehicle Fitment

To ensure this part is compatible with your vehicle, please contact us with your VIN (Vehicle Identification Number). Our technical team can verify the exact fitment before you place your order.

Genuine OEM Parts

Direct from manufacturer

Secure Ordering

Safe and protected checkout

Parts diagram & fitment

87 vehicles

Hex Collared Bolt — locate Hex Collared Bolt in the official exploded view and explore the surrounding assembly.

Standard part (a norm part such as a bolt, nut or clip) — used across many models; the vehicle list shows where this exact number is fitted.

Parts in this assembly46

Vehicle fitment table87

Europe (60)

Vehicle	Years	Pos.	Qty	PR
New Beetle 06>	2005-	6	4	G0E
CADDY-KOMBI/KASTENW. 06>	2005-	35	2
POLO CLASSIC 06>	2005-	35	2
Jetta/Wagon	2002-2006	6	4
GOLF CABRIO	2002-2002	30	2	M60
TOLEDO/LEON/LEON-4	2001-2006	6	2
New Beetle	2001-2005	6	4	G0E
GOLF/VAR./4MOT. A4 02	2001-2002	6	4
Jetta Wagon 02	2001-2002	6	4
Jetta Wagon	2001-2001	6	4
OCTAVIA/COMBI/4X4 01>	2000-	6	2
AUDI A3/S3/QUATTRO	2000-2003	6	2	G0E
CORDOBA/VARIO	1999-2002	35	2
IBIZA	1999-2002	35	2
POLO CLASSIC/VARIANT	1999-2001	35	2
caddy combi./del.van	1998-2005	35	2
New Beetle	1998-2001	6	4
GOLF CABRIO	1998-2001	30	2
TOLEDO/LEON/LEON-4	1998-2001	6	4
Golf	1998-2000	6	4
TRANSPORTER SYNCRO	1996-2003	6	4
AUDI A3/S3/QUATTRO	1996-2000	6	4
OCTAVIA/COMBI/4X4	1996-2000	6	4
GOLF VAR./VENTO	1996-1999	35	2
POLO CLASSIC/VARIANT	1996-1999	35	2
TOLEDO SEAT MOD.97>99	1996-1999	18	2
IBIZA/CORDOBA/VARIO	1996-1999	35	2
Golf	1996-1997	35	2
Transporter 96	1996-1996	6	4
CADDY-KOMBI/KASTEN	1995-2003	22	2
INCA (SEAT-VAN)	1995-2003	22	2
Polo Classic 96	1995-1996	35	2
Golf 96	1995-1996	35	2
Golf Var./Vento 96	1995-1996	35	2
TRANSPORTER SYNCRO	1995-1995	6	4
Passat	1994-1997	16, 35	2
Derby (MEX)	1994-1996	35	2
Golf Cabrio	1994-1996	30, 6	2
Passat Var.syncro	1994-1996	35	2
Golf/Ecomatic 95	1994-1995	35	2
Golf Var./Vento 95	1994-1995	35	2
Golf/Var. syncro	1993-1997	35	2
Jetta GLX 94	1993-1994	35, 6	2
Ibiza/Cordoba (SEAT)	1992-1996	22	2
Transporter syncro	1992-1995	6	4
TOLEDO SEAT	1991-1996	18	2
GOLF/Ecomatic	1991-1994	35, 6	2
Passat syncro	1991-1993	16, 3	2
Passat	1991-1993	16, 35	2
Corrado	1989-1995	16, 21	2
LT, LT 4x4 (28-55)	1989-1995	6	2
Passat	1989-1991	16, 35	2
Jetta	1989-1991	30, 22	1
Jetta 89	1988-1989	19, 22	2
GOLF,JETTA (MEX)	1987-1992	19	2
Jetta 88	1987-1988	19, 22	2
Jetta 87	1986-1987	19, 22	2
Golf/Jetta syn, Rallye	1985-1991	22, 15	2
Jetta 86	1985-1986	19, 22	2
Jetta 85	1984-1985	19, 22	2

Other markets (22)

Vehicle	Years	Pos.	Qty	PR
Golf Brasil "BR."08>	2007-	6	4
Jetta City "MEX"05>07	2006-2007	6	2	G0E
AUDI A3 "BR."M.06>	2005-2006	6	4
Golf 'R32' n. "USA"	2004-2004	6	4
Golf "BR.","USA"03>07	2002-2007	6	4	G0E
Jetta USA	2001-2005	6	4	G0E
Golf BR/US	2001-2002	6	4
AUDI A3-BRASIL.	2000-2005	6	4
Golf BR/US	1999-2001	6	4
Eurovan	1998-2003	6	4
Golf Cabrio "USA","Mex"99>02	1998-2002	30	2
Jetta "USA"99>01	1998-2001	6	4
Eurovan 98	1997-1998	6	4
POLO CLASS./PL. "ZA"	1996-2003	35	2
Golf/Jetta "USA","Mex"97>99	1996-1998	30	2
Eurovan	1996-1997	6	4
Golf Cabrio "USA","MEX"96>99	1995-1998	30	2
Eurovan F>>70-T 96	1995-1995	6	4
Eurovan 95	1994-1995	6	4
Golf/Jetta "USA","MEX"93>96	1992-1996	30, 6	2
JETTA (FAW) 91>	1991-	22, 16	2
Eurovan	1991-1994	9	2

Platform / generic diagrams (5)

Vehicle	Pos.	Qty	Remark
1J0 platform	6	4	1JM
701 platform	14
6K0 platform	35	2
6K0 platform	35	2
6K0 platform	35	2	AKL,AGR,AGP
