Number 6 marks the part’s position in the exploded view.
Product overview
Genuine OEM Volkswagen Socket Head Collared Bolt, part number N10687202. This bolt is designed to secure electrical components and the high-voltage battery system. It is highlighted at position 6 in the diagram. The bolt has a length of 0.055 m and a width of 0.023 m. Genuine OEM collared bolts offer precise alignment and secure fastening for sensitive electrical and high-voltage systems, ensuring safety and performance.
Catalogue entry: SCREW M10X45 ×6.
Fitted with: 1K0260885B RETAINER, 03L260817 SLEEVE, N90707502 BOLT.
Technical details
- Category
- Battery & Charging
- Country of origin
- Germany
- Customs (HS) code
- 73181558
- Manufacturer
- Volkswagen
- Product Type
- Genuine new auto parts
- Shipping size (L × W × H)
- 5.5 × 2.3 × 2.3 cm
- Shipping weight
- 0.04 kg
Specifications
As recorded in the manufacturer’s parts catalogue for this part number.
- Thread
- M10x45 mm
Why buy from WW Spares?
- ✓ Genuine OEM inventory sourced directly from factory networks
- ✓ Fitment support from workshop-seasoned parts specialists
- ✓ Global logistics with customs-ready documentation
Need help confirming compatibility? Talk to a specialist
Parts diagram & fitment
44 vehiclesScrew — locate N10687202 Volkswagen Socket Head Collared Bolt | Genuine OEM in the official exploded view and explore the surrounding assembly.
Standard part (a norm part such as a bolt, nut or clip) — used across many models; the vehicle list shows where this exact number is fitted.
Parts in this assembly22
- 1Compressor 1K0820808BX
- 1Compressor 1K0820859F
- 1Compressor 1K0820859QX
- 1Compressor 1K0820859SX
- 1Compressor 1K0820808A
- 1Compressor 1K0820808AX
- 1Compressor 1K0820859S
- 1Compressor 1K0820859T
- 1Compressor 1K0820859TX
- 3Bracket 022260089M
- 3Bracket 036260883
- 3Retainer 03C903143B
- 3Bracket 06F903143E
- 3Bracket 06F903143F
- 3Retainer 1K0260885B
- 4Sleeve 07K260817
- 5Bolt N90707502
- 8Part 1K0820812B
- 8Part 1K0820812C
- 8Part 4B0260810B
- 9Part G052154A2
- 9Part G052300A2
Vehicle fitment table44
Europe (40)
| Vehicle | Years | Pos. | Qty | Remark | PR |
|---|---|---|---|---|---|
| Altea XL Reference | 2013-2013 | 6 | 6 | TW0 | |
| Audi R8 qu. 5.2 | 2012-2015 | 3 | 3 | L0L | |
| Tiguan 4Motion | 2011-2018 | 6 | 6 | ||
| Golf Cabriolet | 2011-2016 | 6 | 6 | ||
| Golf Plus | 2011-2014 | 6 | 6 | PR:T53,TF0, | |
| Golf | 2011-2013 | 6 | 6 | ||
| Audi A1 Sportback | 2010-2015 | 2 | 6 | TA2 | |
| Sharan Blue Motion | 2010-2015 | 6 | 6 | ||
| Caddy Maxi Kombi | 2010-2015 | 2 | 6 | ||
| Audi TTS Coupe 2.0 | 2010-2014 | 2 | 6 | ||
| Altea XL Reference | 2010-2013 | 6 | 6 | TW0 | |
| Alhambra Stylance | 2010-2013 | 6 | 6 | TF0 | |
| Leon Stylance | 2010-2012 | 6 | 6 | TW0 | |
| Golf Plus 1.6 | 2009-2011 | 6 | 6 | PR:T53,TF0, | |
| Audi A3 Sportback | 2008-2013 | 2 | 6 | ||
| Audi A6 2.7 TDI | 2008-2011 | 15 | 5 | D75 | |
| golf 2.0 | 2008-2011 | 6 | 6 | ||
| Touran 1.9 | 2008-2010 | 2 | 6 | ||
| Audi TT Coupe/Roadster 08> | 2007- | 2 | 6 | ||
| Audi R8 08> | 2007- | 3 | 3 | L0L | |
| Audi A3/S3/Sportb./qu. 08 | 2007- | 2 | 6 | ||
| TIGUAN 08> | 2007- | 6 | 6 | ||
| Audi A3 Cab. 2.0 TDI | 2007-2013 | 2 | 6 | ||
| TOURAN | 2006- | 2 | 6 | ||
| ALTEA 07> | 2006- | 6 | 6 | TW0 | |
| LEON 06> | 2005- | 6 | 6 | TW0 | |
| Audi A3/S3/quattro | 2005-2007 | 2 | 6 | ||
| Audi A6/S6/Avant/qu. 05> | 2004- | 15 | 5 | D75 | |
| Audi A4/S4 Cabrio./qu. | 2002-2006 | 5 | 3 | T0L | |
| Audi TT Coupe/Roadster | 2002-2006 | 6 | 4 | ||
| Audi A4/S4/Av./qu. | 2001-2004 | 5 | 3 | ||
| Audi A6/Wagon/quattro | 2001-2004 | 9, 5 | 4 | T6V | |
| AUDI A3/S3/QUATTRO | 2000-2003 | 6 | 5 | 9AA | |
| Audi TT Coupe/Roadster | 1999-2002 | 6 | 4 | ||
| Audi A4/Avant | 1999-2001 | 9 | 1 | ALZ | |
| Audi A6/Avant | 1997-2001 | 9 | 1 | ||
| Audi A6/Av.qu.F4B-W-> | 1997-2001 | 9 | 1 | ||
| Audi A4/Avant F8D-W-> | 1997-1998 | 11 | 4 | AHL | |
| AUDI A3/S3/QUATTRO | 1996-2000 | 6 | 6 | ||
| Audi A4 F>8D-W-.. | 1995-1997 | 11 | 4 | AHL |
Other markets (4)
| Vehicle | Years | Pos. | Qty | Remark | PR |
|---|---|---|---|---|---|
| Golf Brasil "BR."08> | 2007- | 6 | 5 | ||
| Golf/Rabbit 08> | 2007- | 6 | 6 | TF | |
| AUDI A3 "BR."M.06> | 2005-2006 | 6 | 5 | ||
| Golf "BR.","USA"03>07 | 2002-2007 | 6 | 5 |
