Number 8 marks the part’s position in the exploded view.
Product overview
Genuine OEM Volkswagen Hexagon Flange Screw, part number N90921801. This screw has a hexagonal head and an integrated flange that acts as a washer, distributing load and providing a secure connection. It is used in the engine assembly. Genuine OEM flange screws are critical for ensuring proper torque and load distribution, preventing damage to components and maintaining the structural integrity of the engine.
Technical details
- Category
- Engine
- Customs (HS) code
- 73181558
- Manufacturer
- Volkswagen
- Product Type
- Genuine new auto parts
- Shipping size (L × W × H)
- 3.7 × 2.2 × 2.2 cm
- Shipping weight
- 0.02 kg
Parts diagram & fitment
18 vehiclesHexagon Flange Screw — locate N90921801 Volkswagen Hexagon Flange Screw | Engine in the official exploded view and explore the surrounding assembly.
Parts in this assembly(28)
- 1Assembly 4KE616005E
- 2Control Unit 4M0907778
- 3Repair Kit 4K0698999C
- 4Repair Kit 4K0698505
- 5Repair Kit 4H0698649
- 6Rep Set 4K0616703A
- 10Exhaust Si 80A616010
- 11Part N90495301
- 12Hose 4KE616091B
- 13Valve 4KE616013A
- 13Valve Unit 4N0616013A
- 14Screw N10721401
- 15Repair Kit 4K0698030A
- 17Press ResRight4KE616204A
- 17Press ResLeft4KE616203A
- 20Connection 7L0616758
- 21Connection 4B0616751
- 23Housing 1J0973752
- 26Insulation 4KE616114D
- 27Ut"hex Nut Self-locking With Washer Hex Nut N90570805
- 28Bolt N91207001
- 41Clamp N90686701
- 54Rep Set 4M0698141
- 56Rep Set 4M0698141A
- 57Part D422S25A2
- 58Cable Tie 4F0971850A
- 58Cable Tie N90937702
- 58Cable Tie 4G0971818
Diagrams & fitment data powered by oemdiagrams.com
N90921801 Volkswagen Hexagon Flange Screw | Engine is fitted on: Audi e-tron 2020-2023; Audi Q4 Sportback 2021-2022; Audi Q5 e-tron 2021-; Audi Q4 Sportback 2022-; Audi Q8 e-tron 2018-2020; Audi A1 sportback 1.0 2018-; Audi Q5 2016-2020; ID.4 Pro 2020-2023; ID.4 X 2020-; Multivan 2021-; ID.6 X 2021-; Tiguan 2.0 2023-; ID.7 Limousine Pro 2023-; Amarok twin cab 2016-2022; Leon style 2019-; Formentor TSI CUPRA 2020-; Tavascan Cupra 2023-; Enyaq 2020-.
