Number 32 marks the part’s position in this exploded view (Audi A8 (2013-2018)).
Other diagrams in the gallery may use a different number for the same part.
Product overview
Genuine OEM Volkswagen Bolt, part number WHT004733. Fits Audi A8 (2013-2018). Shown as position 2 in the electrics diagram 771947000.
Catalogue entry: BOLT M6X25.
Technical details
- Category
- Lighting
- Diagram sheet
- Audi 771121180, position 32
- ETKA group
- 9 / 47 (947)
- Manufacturer
- Volkswagen
- Product Type
- Genuine new auto parts
Specifications
As recorded in the manufacturer’s parts catalogue for this part number.
- Thread
- M6x25 mm
Equipment codes
- F0A
- F0X
- F4F
- F5B
- F6M
- K8B
- K8L
PR codes identify the factory option a part belongs to; your vehicle’s are listed on the data sticker in the boot well or service booklet.
Why buy from WW Spares?
- ✓ Genuine OEM inventory sourced directly from factory networks
- ✓ Fitment support from workshop-seasoned parts specialists
- ✓ Global logistics with customs-ready documentation
Need help confirming compatibility? Talk to a specialist
Parts diagram & fitment
2 vehiclesBolt — locate WHT004733 Volkswagen Bolt in the official exploded view and explore the surrounding assembly.
Standard part (a norm part such as a bolt, nut or clip) — used across many models; the vehicle list shows where this exact number is fitted.
Parts in this assembly48
- 1Hose 4H0121101S
- 2Seal Ring 4E0121666
- 3Spring 4E0121142
- 4Water Pipe 057121071AN
- 5Seal Ring N90713202
- 6Bolt N10451408
- 7Screw N91136101
- 8Hose 057121106
- 9Water Pipe 057121491H
- 10Water Pipe 057121597Q
- 11Seal Ring N91008401
- 12Bolt N10405604
- 13Water Pipe 057121492Q
- 14Connection 059121131B
- 15Seal Ring N90783401
- 16Bracket 057121077
- 17Bolt N10156206
- 18Water Pipe 057121598M
- 20Hose 057121086M
- 21Screw N91043801
- 22Seal Ring N0138076
- 25Hose 4H0121053E
- 26Water Pipe 4H0121481Q
- 27Bolt N90797601
- 28Hose 4H0121104H
- 29Bracket 4H0121305AN
- 30Grommet 4F0129669F
- 31Bush 1K0129734B
- 35Valve 4H0121671G
- 36Screw N91032702
- 39Hose 4H0121448S
- 40Hose 4H0121056N
- 41Hose 4H0121082AE
- 42Water Pipe 4H0121400AH
- 43Bolt N10124306
- 44Bolt N10347804
- 45Hose 4H0121449N
- 46Water Pipe 4H0121485AJ
- 49Screw N91049101
- 50Hose 4H0121445H
- 51Pipe 4H0121081M
- 52Hose 4H0121107J
- 53Clip 7L5253198
- 54Pipe 4H0121081AA
- 70Clamp N90686701
- 72Clamp N90770201
- 74Clamp N90926401
- 75Clamp N90686902
Vehicle fitment table2
Europe (2)
| Vehicle | Years | Pos. | Qty |
|---|---|---|---|
| Audi A8L qu. 3.0 TDI | 2013-2018 | 32, 8, 14, 33 | 2 |
| Audi A8L qu. 3.0 TDI | 2009-2014 | 2, 16 | 1 |
Diagrams & fitment data powered by oemdiagrams.com
WHT004733 Volkswagen Bolt is fitted on: Audi A8L qu. 3.0 TDI 2013-2018; Audi A8L qu. 3.0 TDI 2009-2014.
