Number 1 marks the part’s position in the exploded view.
Product overview
Genuine OEM Audi Oil Pan Gasket, part number 03N103647. This gasket forms a vital seal between the engine oil pan and the engine block, preventing oil leaks and maintaining proper lubrication. It is installed at the base of the engine, sealing the oil sump. Weighing 0.221 kg with a thickness of 0.006 m, this gasket is made from durable material designed to withstand engine temperatures and pressures. Choosing a genuine OEM gasket ensures a perfect fit and reliable sealing, crucial for engine integrity and preventing costly oil loss.
Technical details
- Category
- Gaskets & Seals
- Country of origin
- Germany
- Customs (HS) code
- 84099100
- Manufacturer
- Audi
- Product Type
- Genuine new auto parts
- Shipping size (L × W × H)
- 37 × 34 × 0.6 cm
- Shipping weight
- 0.22 kg
Parts diagram & fitment
45 vehiclesCover Plate — locate 03N103647 Audi Oil Pan Gasket | Genuine OEM in the official exploded view and explore the surrounding assembly.
Parts in this assembly(17)
- 2Spacer Pl 0CW103551A
- 2Spacer Pl 0GC103551A
- 3Tube 05L103634A
- 4Oil Dipsti 05L115611
- 5Seal Ring WHT001969
- 6Seal Ring N90043201
- 7Bolt N10451405
- 9Sleeve 01E301153H
- 9Sleeve 022103139B
- 10Cover 05L103660
- 11Spring Rivet 03L863788A
- 12Insulation 05L103954E
- 12Insulation 05L103954G
- 13Screw N90903902
- 14Insulation 05L103954P
- 14Insulation 05L103954H
- 15Hose 05L103493A
