Number 1 marks the part’s position in the exploded view.
Product overview
5Q0201055BE Genuine OEM Volkswagen Fuel Lines Set, part number 5Q0200059LL. This set transports fuel from the tank to the engine, ensuring consistent and reliable fuel supply. It is positioned as part 1 in the diagram. Genuine OEM fuel lines are manufactured to exact specifications, ensuring proper flow rates and preventing leaks, which is critical for engine performance and safety.
Technical details
- Category
- Fuel System
- Country of origin
- Spain
- Customs (HS) code
- 87089997
- Manufacturer
- Volkswagen
- Product Type
- Genuine new auto parts
- Shipping size (L × W × H)
- 125 × 80 × 106 cm
- Shipping weight
- 9.56 kg
Parts diagram & fitment
6 vehiclesFuel Tank — locate 5Q0201055BE 5Q0200059LL Volkswagen Fuel Lines Set | Genuine OEM in the official exploded view and explore the surrounding assembly.
Superseded by 5Q0201055BG — the later replacement part.
This part is marked discontinued by the manufacturer; contact us to check current availability.
Parts in this assembly(27)
- 1Container 5Q0201055AA
- 1Container 5Q0201055AQ
- 1Container 5Q0201055BA
- 2Line 5Q0201931K
- 2Line 5Q0201931N
- 3Fuel Line 5Q0201293E
- 4Part 5Q0201607L
- 5Part 5Q0201550J
- 6Seal Ring 1K0201557A
- 7Clip 1J0201250
- 8Heat Sh 5Q0201307S
- 9Part N91068501
- 10Strap 5Q0201653A
- 10AStrap 5Q0201654A
- 11Bolt N91229601
- 12Container 5Q0201801
- 13Bolt N10240003
- 14Clip 1H0201449C
- 15Bolt N90693804
- 16Line 1J0201142A
- 17Bush 1J0201048C
- 18Bush 5Q0201693
- 19Rubber Bush 5Q0201840
- 20Part 1K0201375
- 30Insulation 8K0201274B
- 31Clamp N10203501
- 32Clamp N10198301
Compatible / alternative parts(3)
Diagrams & fitment data powered by oemdiagrams.com
5Q0201055BE 5Q0200059LL Volkswagen Fuel Lines Set | Genuine OEM is fitted on: Golf 1.4 BlueMotion 2012-2017; Golf Estate 2013-2017; Audi A3 Sportback 2012-2016; Audi A3 Sportback 2016-2020; Leon ST Stylance 2012-2016; Octavia 2012-2017.
